JBL Control 23-1 Speaker

4 products sold in last 4 hours

Selling fast! Over 9 people have in their cart

Ultra-compact 3″ two-way speaker delivering clear background and foreground audio
Wide 100° × 100° coverage for even sound distribution with fewer speakers
Powerful 100W continuous program handling for reliable performance
Supports 70V / 100V distributed audio systems and 8Ω direct operation
Weather-resistant enclosure suitable for indoor and outdoor installations
High-quality woven-fiberglass woofer for clean mids and controlled bass
Crisp high frequencies with 0.5″ PEI dome tweeter
Built-in Invisi Ball mounting system for quick, flexible wall mounting
Optional Weather Max grille available for enhanced outdoor protection

23 people are viewing this right now

Estimated Delivery : Up to 4 business days
Free Shipping & Returns : On all orders over $200

Guaranteed Safe And Secure Checkout

Description
Reviews(0)

The JBL Control 23-1 is a compact yet powerful professional installation speaker designed for background and foreground music in both indoor and outdoor environments. Built with JBL Professional sound engineering, it delivers clear vocals, balanced mids, and smooth highs with wide 100° coverage, making it ideal for restaurants, retail stores, cafes, hotels, offices, classrooms, hospitals, malls, and outdoor patios. Despite its ultra-compact size, produces impressive sound output with excellent clarity. It supports 70V / 100V line systems as well as 8-ohm operation, offering maximum flexibility for commercial audio installations across India. The weather-resistant enclosure and mounting system ensure easy installation and long-term reliability in demanding environments.

Specifications

Frequency Range (-10 dB)	70 Hz – 20 kHz
Frequency Response (±3 dB)	95 Hz – 19 kHz
Power Rating	100 W Continuous Program (2 hrs) 50 W (200 W peak) Continuous Pink Noise (2 hrs) 40 W (160 W peak) Continuous Pink Noise (100 hrs)
Maximum Input Voltage	17.2 V RMS (2 hrs), 34.4 V Peak
Maximum SPL (1 m)	103 dB Avg. Continuous Pink Noise 109 dB Peak
Sensitivity (1W / 1m)	86 dB (Avg. 100 Hz – 10 kHz)
Coverage Angle	100° Horizontal × 100° Vertical
Directivity Factor (Q)	5.8 (Avg. 1 kHz – 16 kHz)
Directivity Index (DI)	7.2 dB (Avg. 1 kHz – 16 kHz)
Impedance	8 Ω (THRU setting)
Crossover Type	2nd Order Low-Pass, 2nd Order High-Pass
Transformer Taps	70V: 15 W, 7.5 W, 3.7 W, 1.8 W 100V: 15 W, 7.5 W, 3.7 W THRU: 8 Ω Nominal Insertion Loss < 0.43 dB at any tap
Recommended High-Pass Filter	70 Hz, 24 dB/oct (for all 8Ω, 70V & 100V settings)
Low Frequency Driver	76 mm (3″) woven-fiberglass cone, butyl rubber surround, Weather-Edge protection
High Frequency Driver	13 mm (0.5″) PEI diaphragm with ferro-magnetic fluid
Enclosure	High Impact Polystyrene (HIPS), UV-resistant finish
Grille	Zinc-plated steel grille with TGIC polyester powder coating
Mounting Hardware	Invisi Ball wall-mount system included Optional U-bracket & ceiling mount
Outdoor Capability	IP-44 rated IP-55 with optional Weather Max grille
Input Connectors	Screw-down terminal strip, supports bare wire up to 12 AWG
Agency Rating	Ro HS Compliant, Transformer UL Recognized (UL1876)
Available Colors	Black (RAL9004), White (RAL9016)
