JBL Control 12C/T ceiling speaker

5 products sold in last 2 hours

Selling fast! Over 18 people have in their cart

JBL 3-inch compact ceiling speaker for professional installations
Clear voice and music reproduction for background and paging systems
Wide 130° conical coverage for even sound distribution
Multi-tap transformer for 70V and 100V PA systems
40W continuous program power with low distortion
Durable polypropylene cone with voice coil
Easy ceiling mount installation with backcan and tile support rails
Compact and lightweight design – ideal for commercial spaces

20 people are viewing this right now

Estimated Delivery : Up to 4 business days
Free Shipping & Returns : On all orders over $200

Guaranteed Safe And Secure Checkout

Description
Reviews(0)

The JBL Control 12C/T is a high-quality compact ceiling loudspeaker designed for commercial and professional audio applications. Featuring a 3-inch full-range driver, this speaker delivers clear voice reproduction and smooth background music, making it perfect for offices, schools, hospitals, hotels, retail stores, and public spaces. With a wide 130° coverage angle, the JBL Control 12C/T ensures even sound distribution, while its multi-tap transformer (70V/100V) allows flexible installation in distributed audio systems. Its durable polypropylene cone, voice coil, and robust backcan design provide long-lasting performance and reliability.

3-Inch Full-Range Driver – Clear audio for announcements and background music
Wide 130° Coverage – Even sound distribution across rooms
Flexible Power Handling – 40W continuous program power, suitable for various commercial applications
Multi-Tap Transformer – Supports 70V and 100V distributed audio systems
High Sensitivity & SPL – 84 dB nominal sensitivity, 97 dB continuous, 103 dB peak
Durable Build – Polypropylene cone with rubber surround & voice coil for long life
Easy Installation – Includes backcan and tile support rails for secure ceiling mounting
Compact & Lightweight – Diameter 196 mm × Depth 138 mm, weight 1.6 kg

Specifications

Driver Size	76 mm (3 inch) full-range cone driver
Frequency Range (-10 dB)	68 Hz – 17 kHz
Frequency Response (±3 dB)	95 Hz – 15 kHz
Power Handling	40 W Continuous Program, 20 W Pink Noise (80 W peak)
Transformer Taps	15 W, 7.5 W, 3.8 W @ 70V/100V (1.9 W @ 70V only)
Sensitivity	84 dB (1 kHz – 16 kHz)
Coverage Angle	130° conical
Directivity Factor (Q)	9.8
Directivity Index (DI)	7.4 dB
Maximum SPL (1 m)	97 dB continuous, 103 dB peak (low-impedance); 96 dB (top 70V/100V tap)
Impedance	8 Ω (direct/bypass setting)
Driver Material	Polypropylene cone, butyl rubber surround, Kapton™ voice coil, high-temp voice coil, aluminum coupling ring
Input Connectors	Removable locking 4-pin connector with screw terminals, max wire 12 AWG (2.5 mm²)
Connector Wiring	Pin 1 = + In; Pin 2 = – In; Pin 3 = + Loop Thru; Pin 4 = – Loop Thru
Strain Reliefs	Strain relief for two cables or flex conduits via clamping mechanism
Materials	ABS baffle with UL94-V0 & UL94-5VB flame rating; zinc-plated steel backcan
Safety Agency Compliance	UL1480, UL2043, NFPA90 & NFPA70; transformer UL registered; RoHS, CE, C-Tick N108
Dimensions	Diameter 196 mm × Depth 138 mm
Ceiling Cut out Size	170 mm diameter
Ceiling Thickness Range	Up to 35 mm standard; optional thick-ceiling dog-ears up to 55 mm
Safety Seismic Attachment	One point, top surface
Net Weight	1.6 kg
Shipping Weight	6.7 kg (pair in master carton)
Included Accessories	C-ring support plate, 2 tile support rails, cut out template, paint shield, connector, grille
Optional Accessories	MTC-24NC bracket, MTC-24MR mud-ring, MTC-TCD dog-ears, MTC-48TR tile rail
Color Options	White or Black
Backcan	Formed steel
Baffle/Rim	ABS with UL94-V0 & UL94-5VB flame rating
Plenum Usage	Yes, integrated backcan
