Description
Ahuja AMX 912DP Mixer (9 Channel)
9 Channel With built-in MP3 Player & Digital EffectsAC & 24V DC Operation
- Input Channels: Each Channel has separate 6.3mm (1/4”) balanced phone jack for Mic & Line which accepts both balanced & unbalanced signals.
- USB Playback: Built-in MP3 Player selectable through Channel 9/USB Switch and controllable through an independant USB input volume control. Channel 9 can be used for Mic & Line inputs or USB Playback function.
- Mono/Stereo Output: Mono output is available from Left & Right output jacks when the switch is in ‘Mono’ position.
- Each channel has GAIN, BASS, TREBLE, ECHO, PAN and slide LEVEL controls with CLIP LED indicator.
- Echo section provided with Delay, Repeat & Level controls.
- Stereo RCA IN/OUT for record and playback.
- Headphone output with Level Control for output monitoring.
SPECIFICATIONS
| POWER REQUIREMENTS | AC: 220-240V 50/60Hz, DC: 24v (2×12V Car Battery) |
| MIC INPUT (Impedance/Gain) | 2kΩ/62dB |
| LINE INPUT (Impedance/Gain) | 20kΩ Balanced/42dB, 10kΩ Unbalanced/42dB |
| DISTORTION | < 0.08% |
| FREQUENCY RESPONSE | 30Hz – 20kHz (+0, -1dB) |
| TONE CONTROLS | Bass : ±12dB at 100Hz, Treble : ± 12dB at 10kHz |
| OUTPUT | Line Output LO: -10dBu/+2dBu (200mV/1V), Line Output HI: 0dBu/+17dBu (775mV/5.5V) |
| DELAY SYSTEM | Digital Signal Processing |
| DIGITAL PLAYER | MP3 Player with USB, SD and MMC Card Reader |
| SIGNAL TO NOISE RATIO | >70dB (0dBm, 0.775V) |
| DIMENSIONS | W483 × H93 × D366 mm |
| WEIGHT | 6.90kg |
