Studiomaster V10A active speaker
-
2-way active line array speaker
-
Dual 10″ LF drivers for powerful mid-low output
-
Dual 1.34″ HF compression drivers for clear highs
-
1150W total Class-D amplification (1000W LF + 150W HF)
-
136 dB maximum SPL for high-volume performance
-
60 Hz – 22 kHz wide frequency response
-
120° × 10° dispersion for even coverage
-
Adjustable 0°–10° vertical array angle (1° steps)
-
Built-in DSP with EQ, delay, crossover & limiting
-
Rugged birch-plywood cabinet for touring use
- Estimated Delivery : Up to 4 business days
- Free Shipping & Returns : On all orders over $200
The Studiomaster V10A Active Line Array Speaker is engineered for high-performance professional sound reinforcement across concerts, outdoor events, auditoriums, festivals, DJ setups and touring applications. Built with a premium birch-plywood cabinet and powered by a high-efficiency Class-D amplifier, the V10A delivers exceptional clarity, deep punch, and wide coverage—making it a reliable choice for large-scale audio installations. Equipped with dual 10″ LF/MF woofers and dual 1.34″ HF compression drivers, this system ensures powerful mid-low output and crisp, distortion-free highs. With a massive 136 dB Max SPL, the V10A is designed to project sound evenly over large distances. Its smart DSP processing provides precise control over gain, EQ, crossover, delay, and system protection ensuring consistent audio performance in any environment.
Specifications
| Speaker Type | 2-way active line-array |
| Drivers | 2 × 10″ woofers + 2 × 1.34″ HF compression drivers |
| Amplifier Power | LF 1000 W / HF 150 W |
| Maximum SPL | 136 dB |
| Frequency Response | 60 Hz – 22 kHz (–10 dB) / 70 Hz – 18 kHz (±3 dB) |
| Input Sensitivity | 0 dBu |
| Coverage | 120° × 10° |
| Vertical Spread Angle | 0–10° (1° steps) |
| Cabinet Material | Birch-plywood, weather-resistant |
| Weight | 34 kg |
| Dimensions | 810 × 290 × 490 mm |
| DSP Features | Gain, EQ, crossover, phase, delay, limiting |
