Studiomaster TRX12 passive speaker
-
12″ 2-way passive loudspeaker
-
250W RMS / 500W Program / 1000W Peak
-
Max SPL: 126 dB
-
Frequency response: 50Hz–20kHz
-
Sensitivity: 96 dB
-
Coverage: 80° × 60°
-
LF Driver: 12″ woofer (65mm VC), 8Ω
-
HF Driver: 1.35″ compression driver (34mm VC)
-
Crossover frequency: 2.2 kHz
-
Dual 4-pole connectors
-
Durable, high-strength cabinet
-
Dimensions: 409 × 628 × 472 mm
-
Weight: 23 kg
- Estimated Delivery : Up to 4 business days
- Free Shipping & Returns : On all orders over $200
The Studiomaster TRX12 is a powerful 12-inch 2-way passive PA speaker designed for professional sound reinforcement across India. Built for musicians, DJs, event companies, rental businesses, schools, auditoriums, and houses of worship, this speaker delivers high clarity, deep bass, and wide coverage in any environment. With 250W RMS, 1000W peak power, and a strong 12″ LF driver with a 65 mm voice coil, the TRX12 ensures rich low frequencies and outstanding durability. The 1″ compression HF driver provides crystal-clear vocals and smooth high-frequency response, making it perfect for music playback, speech, and live performances. Featuring an impressive 126 dB max SPL, rugged M10 flying points, and a 35 mm pole mount, is ready for both stage setups and fixed installations. Whether for indoor halls or outdoor events, this speaker guarantees long-lasting performance with excellent reliability.
Specifications
| Cabinet Type | 12″ 2-Way Passive PA Speaker |
| RMS Power | 250W |
| Program (PGM) Power | 500W |
| Peak Power | 1000W |
| Maximum SPL (@1m) | 126 dB |
| Frequency Response | 50Hz – 20kHz |
| Input Sensitivity | 96 dB (1W @ 1m) |
| Coverage (H × V) | 80° × 60° |
| Nominal Impedance | 8 Ω |
| LF Driver | 12″ Woofer with 65mm Voice Coil |
| HF Driver | 1.35″ / 34mm Compression Driver |
| Crossover Frequency | 2.2 kHz |
| Connections | 2 × 4-Pole Speaker Connectors (Parallel) |
| Dimensions (W × H × D) | 409 × 628 × 472 mm |
| Net Weight | 23 kg |
