Studiomaster Club XS12 Compact Mixing Console
19 products sold in last 20 hours
Selling fast! Over 19 people have in their cart
- 12-input compact audio mixer
- 8 mic inputs + 2 stereo inputs
- Clean preamps with EIN -100 dB
- Mic gain 6 dB to +50 dB | Line gain +10 dB to -34 dB
- Wide frequency response: 10 Hz – 20 kHz
- 3-band EQ with 80 Hz low-cut filter
- Built-in DSP effects for vocals & music
- USB/SD & MP3 audio playback
- USB/SD recording support
- Balanced & unbalanced master outputs
- Universal 100–240 V power supply
- Compact and portable – 5.5 kg
25 people are viewing this right now
- Estimated Delivery : Up to 4 business days
- Free Shipping & Returns : On all orders over $200
The Studiomaster Club XS12 is a professional 12-channel mixing console designed for home studios, live events, karaoke, rehearsals, and portable setups. With 8 mic channels and 2 stereo inputs, it allows you to connect multiple microphones and instruments easily. This compact mixer comes with built-in DSP effects, USB/SD recording, and Bluetooth audio playback, giving you full control over your sound. Its 3-band EQ, compression, and low-cut filter ensures clear and balanced audio, while balanced and unbalanced outputs allow flexible connectivity for various setups.
-
Can I use this mixer for live performances?
A-1 Yes, with 12 channels, DSP effects, and multiple outputs, it’s ideal for live sound setups and small events.
-
Does it support recording directly?
A-2 Yes, the USB/SD card functionality allows you to record audio directly to your media device.
-
Can I connect smartphones via Bluetooth?
A-3 Absolutely. The built-in Bluetooth allows wireless audio playback from phones or tablets.
-
Is it suitable for karaoke and home studios?
A-4 Yes, its compact size, EQ controls, and DSP effects make it perfect for home studio, rehearsal, or karaoke use.
-
Does it support professional microphones?
A-5 Yes, all 8 mic channels have high-quality preamps suitable for dynamic and condenser microphones.
Specifications
| Total Inputs | 12 |
| Mic Input Channels | 8 |
| Stereo Input Channels | 2 |
| Gain Range | Mic: 6 dB ~ +50 dB Line: +10 dB ~ -34 dB |
| EIN (Equivalent Input Noise) | -100 dB |
| Frequency Response (Mic Channel) | 10 Hz – 20 kHz (+1/-3 dB) |
| THD (Mic Channel) | 0.1 % |
| Signal-to-Noise Ratio | 80 dB |
| Output Levels | MAX +26 dB (Balanced) / MAX +20 dB (Unbalanced) |
| Channel EQ | Hi: 12 kHz Mid: 2.5 kHz Lo: 45 Hz Lo Cut: 80 Hz |
| MP3/USB/SD Audio Playback | Yes |
| USB/SD Audio Recording | Yes |
| DSP Effects | Yes |
| Power Requirements | 100 V – 240 V ~ |
| Dimensions (W × H × D) | 415 × 80 × 365 mm |
| Weight | 5.5 kg |
