Sonodyne SSP 2015 graphic equalizer
-
Dual-channel 15-band graphic equalizer
-
±6 dB / ±12 dB selectable boost-cut range
-
50 Hz low-cut filter for cleaner sound
-
Wide 10 Hz – 50 kHz frequency response
-
Balanced XLR & TRS inputs/outputs
-
LED level and clipping indicators
-
Rugged rack-mountable design
- Estimated Delivery : Up to 4 business days
- Free Shipping & Returns : On all orders over $200
The Sonodyne SSP 2015 is a professional-grade dual-channel 15-band graphic equalizer engineered to deliver precision sound control for studios, live sound systems, PA installations, and auditoriums across India. Designed for sound engineers and audio professionals, this unit provides unmatched tonal shaping and clarity with 2/3-octave band spacing, switchable ±6 dB / ±12 dB boost-cut range, and a 50 Hz low-cut filter to eliminate unwanted low-frequency rumble. Built with balanced XLR and TRS inputs/outputs, the SSP 2015 ensures clean, noise-free signal transfer and wide compatibility with professional mixers and amplifiers. With a dynamic range over 112 dB and extended frequency response (10 Hz – 50 kHz), it delivers studio-quality sound shaping for every venue. Perfect for recording studios, broadcast setups, stage applications, and installed sound systems, the making it an ideal choice for Indian audio professionals.
Specification
| DESCRIPTION | Stereo Graphic Equalizer |
| FREQUENCY RESPONSE | <10Hz ~ >50kHz, +0.5/ -3dB |
| INPUT CMRR | >40dB, typically >55dB at 1kHz |
| INPUT IMPEDANCE | Balanced 40kΩ, unbalanced 20kΩ Max |
| OUTPUT IMPEDANCE | Balanced 100Ω, unbalanced 50Ω |
| THD + NOISE | <0.004% |
| CROSSTALK | <-80dB, 20Hz ~ 20kHz |
| SIGNAL TO NOISE RATIO | Typically >90dB |
| DIMENSIONS (HxWxD) mm | 1.75″ x 19″ x 6″ |
| POWER CONSUMPTION | 15W |
| NET WEIGHT | 4.8 lbs |
