CMX-IP Network Powered Speaker DI-9723P

Name: CMX-IP Network Powered Speaker DI-9723P
SKU: 16576
Availability: InStock

₹20,331.30 Price excluding tax

8 products sold in last 1 hour

Selling fast! Over 7 people have in their cart

IP Network Powered Speaker with built-in audio decoder for digital PA systems
30W Class-D built-in amplifier for clear and powerful sound output
PoE (Power over Ethernet) support for easy installation and reduced wiring
RJ45 LAN connectivity (10/100 Mbps) for stable network audio transmission
Supports TCP/IP, UDP, ICMP, and IGMP network protocols
Compatible with MP3 and MP2 audio formats
Designed for paging, announcements, and background music systems
Wall-mount design suitable for offices, schools, hospitals, malls, and public areas
High sound clarity with wide frequency response

21 people are viewing this right now

Estimated Delivery : Up to 4 business days
Free Shipping & Returns : On all orders over $200

Guaranteed Safe And Secure Checkout

Description
Reviews(0)

CMX-DI-9723P IP Network Powered Speaker

The CMX-DI-9723P IP Network Powered Speaker is a modern and intelligent IP based public address speaker designed for professional audio broadcasting over LAN or internet networks. This advanced IP PA speaker system allows users to transmit high-quality digital audio directly through an Ethernet network without requiring complex analogy wiring. Equipped with a built-in 30W stereo Class-D amplifier, the speaker delivers clear, powerful sound suitable for announcements, background music, paging, and emergency broadcasting. With support for MP3 and MP2 audio formats and a 16-bit stereo CD quality output, it ensures excellent sound clarity across large areas. The RJ45 Ethernet port allows seamless integration into existing network infrastructure, making it ideal for schools, hospitals, offices, factories, shopping malls, railway stations, airports, and large commercial buildings. The speaker also includes microphone input, auxiliary input, and adjustable bass/treble controls, giving users full flexibility for different audio sources.

Frequently Asked Questions

What is an IP Network Powered Speaker?

A-1 An IP Network Powered Speaker is a digital public address speaker that receives audio through an Ethernet network instead of traditional analogy audio cables.

Where can the CMX-DI-9723P speaker be used?

A-2 It is widely used in schools, hospitals, factories, offices, shopping malls, airports, railway stations, and commercial buildings.

Does this speaker require an external amplifier?

A-3 No, the CMX-DI-9723P has a built-in 30W Class-D amplifier, so it can operate without an external amplifier.

Can I connect a microphone directly to this speaker?

A-4 Yes, the speaker includes a microphone input and auxiliary input for direct audio connections.

Can multiple speakers work together in one system?

A-5 Yes, multiple IP network speakers can be connected through the same network to create a large multi-zone public address system.

Specifications

Model	CMX-DI-9723P
Product Type	IP Network Powered Speaker
Network Input	Standard RJ45 Ethernet Port
Network Speed	10 / 100 Mbps
Communication Protocol	ARP, TCP/IP, UDP, ICMP, IGMP (Group Broadcast)
Audio Format	MP3 / MP2
Sampling Rate	8 kHz – 48 kHz
Audio Mode	16-bit Stereo CD Quality
Frequency Response	20 Hz – 16 kHz (+1 dB / −3 dB)
Total Harmonic Distortion (THD)	≤ 0.1%
Signal to Noise Ratio	> 70 dB
Power Output	30W Stereo Class-D Amplifier (8Ω)
Aux Input	1 × RCA Input (400 mV)
Connectors	RJ45 LAN Port, Speaker Output, Aux Input, Microphone Input
Control Functions	Bass / Treble / Master / Echo / Mute Controls
Indicators	Power Indicator & Status Indicator
Power Supply	220V – 240V AC, 50 Hz
Power Consumption	≤ 40W
Operating Temperature	5°C – 40°C
Humidity	20% – 80%
Dimensions	260 × 140 × 188
