Bosch PLN‑6AI0240 6‑Zone Amplifier

324,572.40 Price excluding tax

10 products sold in last 18 hours
Selling fast! Over 10 people have in their cart
  • 6-Zone all-in-one amplifier for PA & BGM
  • 6 XLR microphone/line inputs with phantom power
  • Built-in USB/SD MP3 player & AM/FM tuner
  • Priority paging & emergency input support
  • Multi-zone background music control
  • Bass & treble tone adjustments ±8 dB
  • 100 V / 70 V / 8 Ω speaker outputs
  • Supports optional call stations & wall panels
  • Rack mountable (3U) or table top installation
21 people are viewing this right now
  • Check Mark Estimated Delivery : Up to 4 business days
  • Check Mark Free Shipping & Returns : On all orders over $200
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
  • Apple Pay
Guaranteed Safe And Secure Checkout

The Bosch PLN‑6AI0240 is a powerful 6-zone all-in-one amplifier designed for public address (PA) systems, background music (BGM), and emergency paging in commercial, institutional, and large building applications. This all-in-one unit combines amplifier, mixer, media player, and tuner, delivering high-quality sound, easy control, and multi-zone flexibility. With six independent zones, built-in USB/SD player, and AM/FM tuner, this amplifier delivers clear sound, reliable paging, and seamless multi-zone control. It supports microphones with phantom power, priority announcements, and emergency inputs, making it a complete PA solution for commercial and institutional spaces in India.

1. What is the Bosch PLN‑6AI0240 used for?

A-1 It is an all-in-one PA system amplifier for background music, paging, and emergency announcements in multi-zone commercial setups.

2. How many zones does it support?

A-2 It supports six independent zones, allowing separate control of music and announcements.

3. Can I connect microphones and music sources together?

A-3 Yes, it has 6 microphone/line inputs and 3 music inputs (USB/SD/FM/AM) for simultaneous use.

4. Does it support emergency announcements?

A-4 Yes, the EMG/telephone input and priority paging ensure announcements always override background music.

5. Is it suitable for schools, hospitals, and offices?

A-5 Absolutely, it is designed for commercial and institutional applications including schools, colleges, offices, hospitals, auditoriums, hotels, and malls.

Specifications

Product Type 6-Zone All-in-One Amplifier for PA & BGM
Rated Output Power 240 W
Mains Power Supply 115/230 VAC ±15%, 50/60 Hz
Fuse Rating 6.3 A (230 VAC) / 10 A (115 VAC)
Max Power Consumption 720 W
Frequency Response (Line Inputs) 50 Hz – 20 kHz (+1/‑3 dB)
Frequency Response (Mic Inputs) 100 Hz – 15 kHz (+1/‑3 dB)
Total Harmonic Distortion (THD) < 1% @ rated output, 1 kHz
Bass Control ± 8 dB @ 100 Hz
Treble Control ± 8 dB @ 10 kHz
Signal-to-Noise Ratio (Mic) > 65 DBA @ max volume
Signal-to-Noise Ratio (Line) > 70 DBA @ max volume
Microphone/Line Inputs 6 × balanced XLR with phantom power
Push-to-Talk / Priority Input 1 supports priority/ducking
Music Inputs 3 × auxiliary line (USB/SD/FM/AM)
Emergency Input 1 × Line input
Built-In Media & Tuner USB/SD MP3 Player, AM/FM Tuner (87.5–108 MHz FM, 531–1602 kHz AM)
Outputs Six independent zones, 100 V / 70 V / 8 Ω speaker outputs
Control & Compatibility Supports 6 optional call stations, optional wall panel remote
Mounting 3U rack mount or table top (brackets included)
Dimensions (H × W × D) 133 × 430 × 365 mm
Net Weight ~18 kg
Operating Temperature ‑10°C to +45°C
Storage Temperature ‑40°C to +70°C
Relative Humidity < 95% non-condensing
