Audio-Technica ATND1061 Ceiling Array Microphone
16 products sold in last 17 hours
Selling fast! Over 17 people have in their cart
- 90° beamforming voice pickup
- 60 Hz–18 kHz clear speech response
- High 102 dB SPL input handling
- Low self-noise and 89 dB dynamic range
- 100 dB analog dynamic range
- Dante & IP control compatible
- PoE-powered (no external power required)
- Compact 227.5 × 227.5 × 30 mm design
- UL 2043 plenum-rated for safe installation
- Complete mounting accessories included
23 people are viewing this right now
- Estimated Delivery : Up to 4 business days
- Free Shipping & Returns : On all orders over $200
The Audio-Technica ATND1061 is a next-generation ceiling array microphone designed for boardrooms, huddle rooms, conference halls, training rooms, classrooms, and corporate AV setups. With advanced beam forming technology, multiple coverage zones, and seamless PoE network connectivity, it captures voices clearly from anywhere in the room—without the need for table microphones or messy cabling. Built for professional conferencing, this microphone delivers crystal-clear audio for platforms like Zoom, Microsoft Teams, Google Meet, Cisco and all major video-conferencing systems. Its clean, low-profile design blends perfectly into any ceiling, making it ideal for modern meeting environments in India.
Specifications
Microphone
| Beam Width | 90° |
| Polar Pattern | Beamforming pattern |
| Frequency Response | 60 Hz – 18,000 Hz |
| Max Input Sound Level | 102 dB SPL |
| Sensitivity | –8 dBFS (1 kHz, 94 dB SPL) |
| Dynamic Range | 89 dB (A-weighted) |
| Signal-to-Noise Ratio | 61.5 dB (A-weighted) |
| Self Noise | 25 dB SPL (A-weighted) |
Analog Audio
| Frequency Response | 20 Hz – 20 kHz (+1.0 / –2.0 dB) |
| Dynamic Range | 100 dB (A-weighted) |
| Signal-to-Noise Ratio | 80 dB (A-weighted) |
| Headroom | 20 dB |
| Residual Noise | –75.8 dBu (A-weighted) |
| THD | <0.1% (1 kHz, unity gain) |
| Analog Input Levels | MIC Max: –30 dBu MIC Unity: –50 dBuLINE Max: +12.2 dBuLINE Unity: –10 dBV (switchable) |
| Analog Output Levels | Max: +19.2 dBu Unity: +4 dBu / –10 dBV / –33 dBV (switchable) |
General Specifications – Beamforming Array
| Power Requirement | PoE (IEEE 802.3af Class 0) |
| Power Consumption | Max. 7 W |
| Operating Temperature | 0°C to 40°C |
| Operating Humidity | 25% to 85% RH (non-condensing) |
| Dimensions | 227.5 × 227.5 × 30 mm (9.0″ × 9.0″ × 1.2″) |
| Weight | 1250 g (44 oz) |
| Network | Dante: 1 GbpsIP Control: 100 Mbps |
| Digital Audio | 48 kHz sampling rate, 24-bit depth |
| Latency | Mic CH1–CH6: 47 msMic Auto Mix: 79 msDante: 0.25–5 ms |
| I/O Connectors | Dante/Network (ATND1061DAN): RJ-45A-T LINK (ATND1061LK): RJ-45Analog In: 3-pin EuroblockAnalog Out: 3-pin EuroblockGPI: 3-pin Euroblock |
| Phantom Power | Analog Input: 12 V |
| Included Accessories | IR Remote Controller, Surface Mount Adapter, Screws (M4×50mm ×4 / M4×10mm ×12), Flush Mount Adapter, Flush Mount Cover, Hole Cover, Nut ×4, Snap Bushings ×2, Tile Bridge A ×2, Tile Bridge B ×2, Tile Bridge C ×4, Seismic Cable, Zip Tie, Safety Belt, Euroblock Connectors ×3, Installation Template |
