Audio-Technica ATDM-0604a digital mixer

Name: Audio-Technica ATDM-0604a digital mixer
Brand: Audio-Technica
SKU: 13972
Availability: InStock

Original price was: ₹92,736.Current price is: ₹53,690. Price excluding tax

14 products sold in last 5 hours

Selling fast! Over 2 people have in their cart

6-input automatic digital mixer with smart gain control
Echo- and noise-canceling algorithms for clear conferencing
4 balanced mic/line inputs with phantom power
Dante network audio interface for flexible routing
USB connectivity for soft-codec conferencing and recording
Built-in auto-mixing for smooth level management
Powerful DSP with EQ, HPF, gating, and compression
Easy configuration via web remote interface
Ideal for meeting rooms, classrooms, and AV installations
Supports GPIO for external control integration

26 people are viewing this right now

Estimated Delivery : Up to 4 business days
Free Shipping & Returns : On all orders over $200

Guaranteed Safe And Secure Checkout

Description
Reviews(0)

The Audio-Technica ATDM-0604a is a premium 6-channel digital Smart Mixer designed for professional conferencing, boardrooms, classrooms, hybrid meetings, worship spaces, and live sound applications. Built with advanced DSP technology, automation, and powerful acoustic processing, it ensures clear, consistent, hands-free audio mixing—ideal for modern AV installations. This mixer delivers outstanding audio quality with a 20 Hz–20 kHz frequency response, 110 dB dynamic range, AEC (Acoustic Echo Cancellation), feedback suppression, and per-channel DSP. With flexible I/O options, USB audio, IP control, and cascading support for up to eight mixers, the is built for scalable, high-performance audio environments across India. With 6 balanced mic/line inputs, USB audio I/O, stereo auxiliary input, and balanced/unbalanced output options, this smart mixer integrates seamlessly with video conferencing systems, sound reinforcement setups, and digital platforms like Zoom, Teams, Google Meet, and more.

Specifications

Maximum Gain	64 dB
Frequency Characteristics	20 Hz – 20 kHz (MIC -16 dBu): +1.0 / -1.0 dB 20 Hz – 20 kHz (MIC -60 dBu): +1.0 / -2.0 dB 20 Hz – 20 kHz (LINE 24 dBu): +1.0 / -1.0 dB 20 Hz – 20 kHz (LINE -40 dBu): +1.0 / -2.0 dB
Dynamic Range	110 dB or higher, A-weighted / ST
Signal-to-Noise Ratio	90 dB or higher, A-weighted / ST
Headroom	20 dB or higher
Input Referred Noise	-126 dBu or less (Rs = 150 Ω, DIN)
Common-Mode Rejection Ratio	80 dB or higher (1 kHz)
Residual Noise	-86 dBu or less, A-weighted
Channel Separation	-80 dB or less (1 kHz, unity gain)
Total Harmonic Distortion	0.03% or less (1 kHz, unity gain)

Analog Inputs

MIC 1–6	Max: 0 dBu / Unity: -40 dBu
LINE 1–4	Max: +10 dBV / Unity: -10 dBV
LINE 5–6	Max: +24 dBu / Unity: +4 dBu / 0 dBV / -10 dBV / -20 dBV
ST Input	Max: +10 dBV / Unity: -10 dBV / -20 dBV

Analog Outputs

Unbalanced Output	Max: +10 dBV / -13 dBV; Unity: -10 dBV / -33 dBV
Balanced Output (1/L, 2/R)	Max: +24 dBu / +20 dBV / +10 dBV; Unity: +4 dBu / 0 dBV / -10 dBV

Power & Operating Conditions

Phantom Power	+48V DC
Power Supply	100–240 V AC (50/60 Hz)
Power Consumption	17 W
Operating Temperature	0–40°C
Operating Humidity	25–85% (no condensation)

Dimensions	219.3 mm (W) × 346.3 mm (D) × 44 mm (H)
Weight	1.89 kg (4.2 lbs)
Finish	Front Panel: Black with silver lines Sides/Rear: Black
Pad (Attenuation Level)	-24 dB
Connectors
Inputs	ST Input (3-pin)MIC/LINE 1–6 ( 3-pin)
Outputs	Unbalanced Output ( 3-pin)Balanced Outputs 1/L, 2/R (3-pin)
GPO	(3-pin)
Level Indicator	Signal/Peak (Red/Yellow/Green)Peak Indication: -5 to 0 dBP eak Hold: 2 sec
Remote / Network Control
IP Remote Control	RJ-45 × 1Factory IP: 192.168.33.102Speed: 100 Mbps
Network Port	RJ-45 × 1
LINK I/O	Audio-Technica LINK: RJ-45 × 4 (100 Mbps)
USB Type-B	Stereo Input × 1 & Stereo Output × 1 (24-bit, 480 Mbps)
A/D Converter	24-bit, 115 dB dynamic range
D/A Converter	24-bit, 115 dB dynamic range
Accessories Included	connectors ×11, Rack-mount brackets (large & small), Rack screws ×6, Power cable, Rubber feet ×4
