Continuous Rated Power	.
Stereo/Mono	8Ω : 700W + 700W, 4Ω: 1100W + 1100W 2Ω : 1600W + 1600W
Bridged Output	8Ω : 2200W, 4Ω : 3200W
THD + N	< 1.0%
Frequency Response (-3dB)	20-20,000Hz
Power Bandwidth (0.5% THD)	20-20,000Hz
Input Sensitivity	0dBu (775mV), 4dBu (1.23V) (Selectable)
Input Impedance	10k Unbalanced, 20k Balanced
Signal to Noise Ratio	> 95dB
Channel Separation	> 65dB at 1kHz
Damping Factor	400 : 1 (8Ω)
Slew Rate	35V/µs
Protections	Temperature, DC, RFI, Short Circuit, Overload, Built-in Limiter AC: Fuse 25Amp. (T 25A L); ± DC: Fuse 2 x 25Amp. (T 25A L) for each channel, Fuse 2×3 Amp. (T 3A L)
Input Connectors	2 × XLR, Stereo Phone Jack 6.3mm
Output Connectors	Speakon 4-Way and heavy-duty Binding Post for each channel
Cooling	Variable Speed DC Fan with Temperature Sensing
Front Panel Controls	2 × 41 Step Level Attenuators
Indicators	Power ON, Signal, Clip, Temperature, Protect (Ch. A & B)
Power Consumption (Rated)	3900VA @ 220-240V ~ 50/60Hz
Dimensions	W482 × H153 × D550mm
Weight	33.00kg
